Performance Table rpm:2850, Feq 50Hz @ Rated Voltage
Fr-2 Duty Head 15 Feet Stage @ 35 LPM Outlet 1"
HP Stage Lpm 20 25 30 35 40 45 50 55 60
0.5 10 Head In Mtr 60 55 48 41 33 26 20 15 10
0.75 12 72 66 55 49 40 31 24 18 12
1 15 90 83 72 62 50 39 30 23 15
1 18 108 99 86 74 59 47 36 27 18
1.5 25 150 138 120 103 83 65 50 38 25
2 30 180 165 144 123 99 78 60 45 30
3 35 210 193 168 144 116 91 70 53 35
5 40 240 220 192 164 132 104 80 60 40

Fr-3 Duty Head 15 Feet Stage @ 50 LPM Outlet 1.25"
HP Stage Lpm 35 40 45 50 55 60 65 70 75
0.5 1 Head In Mtr 43 41 37 31 27 22 18 12 7
0.75 10 61 58 53 44 38 31 25 17 10
1 12 73 70 64 53 46 37 30 20 12
1.5 20 122 116 106 88 76 62 50 34 20
2 25 153 145 133 110 95 78 63 43 25
3 30 183 174 159 132 114 93 75 51 30
5 35 214 203 186 154 133 109 88 60 35

Fr-6 Duty Head 15 Feet Stage @ 110 LPM Outlet 1.25"
HP Stage Lpm 80 90 100 110 120 130 140 150 150
0.75 8 Head In Mtr 44 40 36 33 29 24 20 15 8
1 10 55 50 45 41 36 30 25 18 10
1.5 12 66 60 54 49 43 36 30 22 12
2 15 83 75 68 62 54 45 38 27 15
3 20 110 100 90 82 72 60 50 36 20
5 25 138 125 113 103 90 108 63 46 25

Fr-8 Duty Head 15 Feet Stage @ 120 LPM Outlet 1.5"
HP Stage Lpm 80 90 100 110 120 135 150 160 170
1 6 Head In Mtr 35 32 29 27 24 21 17 13 8
1.5 8 46 43 39 36 32 28 23 18 10
2 10 58 54 49 45 40 35 29 22 13
3 15 87 81 74 68 60 53 44 33 20
3 18 104 97 88 81 72 63 52 40 23
5 20 116 108 98 90 80 70 58 44 26

Fr-10 Duty Head 15 Feet Stage @ 150 LPM Outlet 1.5"
HP Stage Lpm 110 120 130 140 150 160 170 180 190
1 7 Head In Mtr 37 34 32 29 27 21 16 11 7
1.5 8 42 38 36 33 24 24 18 13 8
2 12 64 58 54 49 36 36 28 19 12
3 18 95 86 81 74 54 54 41 29 18

Fr-12 Duty Head 15 Feet Stage @ 225 LPM Outlet 2"
HP Stage Lpm 150 175 200 225 250 275 300 325 350
2 6 Head In Mtr 24 22 20 18 16 13 11 8 3
3 8 32 29 26 24 21 17 14 10 4
5 12 48 43 40 36 31 25 22 16 6

Fr-15 Duty Head 15 Feet Stage @ 245 LPM Outlet 2"
HP Stage Lpm 10 50 68 154 217 245 258 300 335
1 4 Head In Mtr 24 22 20 16 13 12 10 13 4
1.5 5 30 28 25 21 17 15 13 18 5
2 6 36 34 30 25 20 18 16 22 6
3 8 48 45 40 33 26 24 21 33 8
2 10 60 56 50 41 33 30 26 40 10


<
